ATMC102U Mini Color Camera Head, NTSC/PAL, 400 TV Lines, 10.7 × 10.7 mm
$142.00Original price was: $142.00.$113.00Current price is: $113.00.
Mini Color Camera Head — NTSC/PAL Composite Output
1/4″ Color Sensor · 400 TV Lines · 0.6 Lux @ F1.2
Ultra-Compact 10.7 × 10.7 mm Sensor Board with 3.9 mm / F2.8 Lens
Optional Built-in Audio (20–1600 Hz, S/N > 58 dB)
Pairs with AUSBC1 USB Converter for Plug-and-Play PC Connection
The ATMC102U is a miniature color camera head that generates standard NTSC or PAL composite video (and optional audio) from a 1/4″ color image sensor with a 3.9 mm / F2.8 built-in lens. At only 10.7 × 10.7 mm, it embeds directly into microscopes, inspection probes, borescopes and OEM enclosures where a standard webcam will not fit.
It delivers 400 TV lines, 0.6 lux/F1.2 sensitivity and greater than 50 dB signal-to-noise ratio, drawing under 100 mA @5 V. Pair it with the AUSBC1 USB video converter (sold separately) for driver-free USB connection to a computer, or feed the composite output directly to any NTSC/PAL monitor or DVR.
It is used in medical care, microscopy, video conferencing, PC multimedia, pipe and well inspection, and CCTV security surveillance applications.
Specifications
Camera Head Size
10.7 × 10.7 mm
Image Sensor
1/4″ Color Image Sensor
Resolution
400 TV Lines (648 × 488 effective pixels)
Built-in Lens
3.9 mm / F2.8
Sensitivity
0.6 lux / F1.2
Signal-to-Noise Ratio
> 50 dB
Scan Mode
Progressive Scan
Video Output
1 Vp-p @ 75 Ω composite, NTSC / PAL
Audio Output (optional)
20–1600 Hz, S/N > 58 dB
Current Consumption
< 100 mA @5 V (DC 3.3 V – 5 V)
Weight
0.25 lbs
