ATE1-31-1.4A 3.7W 1.4A Thermoelectric Cooler (TEC) Module (8×8mm)
$38.89
Single-Stage Thermoelectric Cooler (TEC / Peltier Module)
Qmax: 3.7 W
Imax: 1.4 A
Vmax: 3.8 V
ΔTmax: 72.5°C
Dimensions: 8 × 8 × 2.7 mm
Sealing: Non-sealed
11 in stock (can be backordered)
Product Overview
ATE1-31-1.4A is a non-sealed, single-stage thermoelectric cooler (TEC / Peltier module) rated 1.4 A, 3.7 W Qmax and 72.5°C ΔTmax in a 8 × 8 mm, 31-couple package (3.8 V Vmax).
Standard non-sealed construction for dry, temperature-controlled environments. Ideal for temperature control of laser diodes, optical components, CCD / IR cameras and bio-tech instruments; pairs with ATI TEC controllers and NTC thermistors.
Specifications
| Qmax | 3.7 W |
| Imax | 1.4 A |
| Vmax | 3.8 V |
| ΔTmax | 72.5°C |
| Lc | 8 mm |
| W | 8 mm |
| H | 2.7 mm |
| Construction / Temp. Range | Non-sealed, single-stage; -55°C to +85°C |
