ATE1-07-3AS 1.7W 3A Thermoelectric Cooler (TEC) Module (8×8mm)
$11.46
Single-Stage Thermoelectric Cooler (TEC / Peltier Module)
Qmax: 1.7 W
Imax: 3 A
Vmax: 0.8 V
ΔTmax: 61.5°C
Dimensions: 8 × 8 × 3.39 mm
Sealing: Sealed
Discount per Quantity
| Quantity | Price |
|---|---|
| 1 - 4 | $11.46 |
| 5 - 24 | $11.23 |
| 25 - 99 | $11.00 |
| 100 + | $10.77 |
Product Overview
ATE1-07-3AS is a sealed, single-stage thermoelectric cooler (TEC / Peltier module) rated 3 A, 1.7 W Qmax and 61.5°C ΔTmax in a 8 × 8 mm, 7-couple package (0.8 V Vmax).
Its edge-sealed construction blocks moisture for humid or condensing environments. Ideal for temperature control of laser diodes, optical components, CCD / IR cameras and bio-tech instruments; pairs with ATI TEC controllers and NTC thermistors.
Specifications
| Qmax | 1.7 W |
| Imax | 3 A |
| Vmax | 0.8 V |
| ΔTmax | 61.5°C |
| Lc | 8 mm |
| W | 8 mm |
| H | 3.39 mm |
| Construction / Temp. Range | Sealed, single-stage; -55°C to +85°C |
| Weight | 0.2 lbs |
|---|
