R08E96 0805 1% SMD Resistor Kit 510 Values
Price range: $269.00 through $999.00
R08E96 is an 0805 1% SMD resistor kit with 510 values for electronics design, prototyping, repair, and laboratory use.
Quantity options:
R08E96-50 – 50 pieces per value
R08E96-100 – 100 pieces per value
R08E96-200 – 200 pieces per value
R08E96-500 – 500 pieces per value
Product Overview
The R08E96-50-300 is an 0805 1% SMD differential resistor kit covering all 510 values of the E-96 series. Each value is pre-sorted into its own lidded and labeled bin, so locating a specific resistor takes seconds instead of a parts-drawer search.
Quantities are matched to how often a value is actually used: 300 pieces of each commonly used value and 50 pieces of each rarely used value. The kit therefore lasts far longer in service without tying up stock in values that are rarely pulled. It ships in a set of 4 Super SMD Component Enclosures, each with 128 individually lidded and labeled bins.
Resistance vs. Marking Code
The bin lids are labeled with resistance values, but each 0805 resistor carries only a marking code. Most values use a 4-character code: the first three digits are the value and the last digit is the number of zeros. An R marks the decimal point, so 1R00 = 1.00Ω and R100 = 0.10Ω. The 0Ω jumper is marked 0. The 510 values are split across 4 boxes, numbered 4.1 to 4.4, and each table below follows the bin layout of one box.
Box 4.1: 0.0Ω to 147Ω
| 0.0Ω 0 |
0.10Ω R100 |
0.50Ω R500 |
1.00Ω 1R00 |
1.50Ω 1R50 |
2.00Ω 2R00 |
2.49Ω 2R49 |
3.01Ω 3R01 |
4.02Ω 4R02 |
4.99Ω 4R99 |
5.90Ω 5R90 |
6.81Ω 6R81 |
7.50Ω 7R50 |
8.25Ω 8R25 |
9.09Ω 9R09 |
10.0Ω 10R0 |
| 10.2Ω 10R2 |
10.5Ω 10R5 |
10.7Ω 10R7 |
11.0Ω 11R0 |
11.3Ω 11R3 |
11.5Ω 11R5 |
11.8Ω 11R8 |
12.1Ω 12R1 |
12.4Ω 12R4 |
12.7Ω 12R7 |
13.0Ω 13R0 |
13.3Ω 13R3 |
13.7Ω 13R7 |
14.0Ω 14R0 |
14.3Ω 14R3 |
14.7Ω 14R7 |
| 15.0Ω 15R0 |
15.4Ω 15R4 |
15.8Ω 15R8 |
16.2Ω 16R2 |
16.5Ω 16R5 |
16.9Ω 16R9 |
17.4Ω 17R4 |
17.8Ω 17R8 |
18.2Ω 18R2 |
18.7Ω 18R7 |
19.1Ω 19R1 |
19.6Ω 19R6 |
20.0Ω 20R0 |
20.5Ω 20R5 |
21.0Ω 21R0 |
21.5Ω 21R5 |
| 22.1Ω 22R1 |
22.6Ω 22R6 |
23.2Ω 23R2 |
23.7Ω 23R7 |
24.3Ω 24R3 |
24.9Ω 24R9 |
25.5Ω 25R5 |
26.1Ω 26R1 |
26.7Ω 26R7 |
27.4Ω 27R4 |
28.0Ω 28R0 |
28.7Ω 28R7 |
29.4Ω 29R4 |
30.1Ω 30R1 |
30.9Ω 30R9 |
31.6Ω 31R6 |
| 32.4Ω 32R4 |
33.2Ω 33R2 |
34.0Ω 34R0 |
34.8Ω 34R8 |
35.7Ω 35R7 |
36.5Ω 36R5 |
37.4Ω 37R4 |
38.3Ω 38R3 |
39.2Ω 39R2 |
40.2Ω 40R2 |
41.2Ω 41R2 |
42.2Ω 42R2 |
43.2Ω 43R2 |
44.2Ω 44R2 |
45.3Ω 45R3 |
46.4Ω 46R4 |
| 47.5Ω 47R5 |
48.7Ω 48R7 |
49.9Ω 49R9 |
51.1Ω 51R1 |
52.3Ω 52R3 |
53.6Ω 53R6 |
54.9Ω 54R9 |
56.2Ω 56R2 |
57.6Ω 57R6 |
59.0Ω 59R0 |
60.4Ω 60R4 |
61.9Ω 61R9 |
63.4Ω 63R4 |
64.9Ω 64R9 |
66.5Ω 66R5 |
68.1Ω 68R1 |
| 69.8Ω 69R8 |
71.5Ω 71R5 |
73.2Ω 73R2 |
75.0Ω 75R0 |
76.8Ω 76R8 |
78.7Ω 78R7 |
80.6Ω 80R6 |
82.5Ω 82R5 |
84.5Ω 84R5 |
86.6Ω 86R6 |
88.7Ω 88R7 |
90.9Ω 90R9 |
93.1Ω 93R1 |
95.3Ω 95R3 |
97.6Ω 97R6 |
100Ω 1000 |
| 102Ω 1020 |
105Ω 1050 |
107Ω 1070 |
110Ω 1100 |
113Ω 1130 |
115Ω 1150 |
118Ω 1180 |
121Ω 1210 |
124Ω 1240 |
127Ω 1270 |
130Ω 1300 |
133Ω 1330 |
137Ω 1370 |
140Ω 1400 |
143Ω 1430 |
147Ω 1470 |
Box 4.2: 150Ω to 3.16K
| 150Ω 1500 |
154Ω 1540 |
158Ω 1580 |
162Ω 1620 |
165Ω 1650 |
169Ω 1690 |
174Ω 1740 |
178Ω 1780 |
182Ω 1820 |
187Ω 1870 |
191Ω 1910 |
196Ω 1960 |
200Ω 2000 |
205Ω 2050 |
210Ω 2100 |
215Ω 2150 |
| 221Ω 2210 |
226Ω 2260 |
232Ω 2320 |
237Ω 2370 |
243Ω 2430 |
249Ω 2490 |
255Ω 2550 |
261Ω 2610 |
267Ω 2670 |
274Ω 2740 |
280Ω 2800 |
287Ω 2870 |
294Ω 2940 |
301Ω 3010 |
309Ω 3090 |
316Ω 3160 |
| 324Ω 3240 |
332Ω 3320 |
340Ω 3400 |
348Ω 3480 |
357Ω 3570 |
365Ω 3650 |
374Ω 3740 |
383Ω 3830 |
392Ω 3920 |
402Ω 4020 |
412Ω 4120 |
422Ω 4220 |
432Ω 4320 |
442Ω 4420 |
453Ω 4530 |
464Ω 4640 |
| 475Ω 4750 |
487Ω 4870 |
499Ω 4990 |
511Ω 5110 |
523Ω 5230 |
536Ω 5360 |
549Ω 5490 |
562Ω 5620 |
576Ω 5760 |
590Ω 5900 |
604Ω 6040 |
619Ω 6190 |
634Ω 6340 |
649Ω 6490 |
665Ω 6650 |
681Ω 6810 |
| 698Ω 6980 |
715Ω 7150 |
732Ω 7320 |
750Ω 7500 |
768Ω 7680 |
787Ω 7870 |
806Ω 8060 |
825Ω 8250 |
845Ω 8450 |
866Ω 8660 |
887Ω 8870 |
909Ω 9090 |
931Ω 9310 |
953Ω 9530 |
976Ω 9760 |
1.00K 1001 |
| 1.02K 1021 |
1.05K 1051 |
1.07K 1071 |
1.10K 1101 |
1.13K 1131 |
1.15K 1151 |
1.18K 1181 |
1.21K 1211 |
1.24K 1241 |
1.27K 1271 |
1.30K 1301 |
1.33K 1331 |
1.37K 1371 |
1.40K 1401 |
1.43K 1431 |
1.47K 1471 |
| 1.50K 1501 |
1.54K 1541 |
1.58K 1581 |
1.62K 1621 |
1.65K 1651 |
1.69K 1691 |
1.74K 1741 |
1.78K 1781 |
1.82K 1821 |
1.87K 1871 |
1.91K 1911 |
1.96K 1961 |
2.00K 2001 |
2.05K 2051 |
2.10K 2101 |
2.15K 2151 |
| 2.21K 2211 |
2.26K 2261 |
2.32K 2321 |
2.37K 2371 |
2.43K 2431 |
2.49K 2491 |
2.55K 2551 |
2.61K 2611 |
2.67K 2671 |
2.74K 2741 |
2.80K 2801 |
2.87K 2871 |
2.94K 2941 |
3.01K 3011 |
3.09K 3091 |
3.16K 3161 |
Box 4.3: 3.24K to 68.1K
| 3.24K 3241 |
3.32K 3321 |
3.40K 3401 |
3.48K 3481 |
3.57K 3571 |
3.65K 3651 |
3.74K 3741 |
3.83K 3831 |
3.92K 3921 |
4.02K 4021 |
4.12K 4121 |
4.22K 4221 |
4.32K 4321 |
4.42K 4421 |
4.53K 4531 |
4.64K 4641 |
| 4.75K 4751 |
4.87K 4871 |
4.99K 4991 |
5.11K 5111 |
5.23K 5231 |
5.36K 5361 |
5.49K 5491 |
5.62K 5621 |
5.76K 5761 |
5.90K 5901 |
6.04K 6041 |
6.19K 6191 |
6.34K 6341 |
6.49K 6491 |
6.65K 6651 |
6.81K 6811 |
| 6.98K 6981 |
7.15K 7151 |
7.32K 7321 |
7.50K 7501 |
7.68K 7681 |
7.87K 7871 |
8.06K 8061 |
8.25K 8251 |
8.45K 8451 |
8.66K 8661 |
8.87K 8871 |
9.09K 9091 |
9.31K 9311 |
9.53K 9531 |
9.76K 9761 |
10.0K 1002 |
| 10.2K 1022 |
10.5K 1052 |
10.7K 1072 |
11.0K 1102 |
11.3K 1132 |
11.5K 1152 |
11.8K 1182 |
12.1K 1212 |
12.4K 1242 |
12.7K 1272 |
13.0K 1302 |
13.3K 1332 |
13.7K 1372 |
14.0K 1402 |
14.3K 1432 |
14.7K 1472 |
| 15.0K 1502 |
15.4K 1542 |
15.8K 1582 |
16.2K 1622 |
16.5K 1652 |
16.9K 1692 |
17.4K 1742 |
17.8K 1782 |
18.2K 1822 |
18.7K 1872 |
19.1K 1912 |
19.6K 1962 |
20.0K 2002 |
20.5K 2052 |
21.0K 2102 |
21.5K 2152 |
| 22.1K 2212 |
22.6K 2262 |
23.2K 2322 |
23.7K 2372 |
24.3K 2432 |
24.9K 2492 |
25.5K 2552 |
26.1K 2612 |
26.7K 2672 |
27.4K 2742 |
28.0K 2802 |
28.7K 2872 |
29.4K 2942 |
30.1K 3012 |
30.9K 3092 |
31.6K 3162 |
| 32.4K 3242 |
33.2K 3322 |
34.0K 3402 |
34.8K 3482 |
35.7K 3572 |
36.5K 3652 |
37.4K 3742 |
38.3K 3832 |
39.2K 3922 |
40.2K 4022 |
41.2K 4122 |
42.2K 4222 |
43.2K 4322 |
44.2K 4422 |
45.3K 4532 |
46.4K 4642 |
| 47.5K 4752 |
48.7K 4872 |
49.9K 4992 |
51.1K 5112 |
52.3K 5232 |
53.6K 5362 |
54.9K 5492 |
56.2K 5622 |
57.6K 5762 |
59.0K 5902 |
60.4K 6042 |
61.9K 6192 |
63.4K 6342 |
64.9K 6492 |
66.5K 6652 |
68.1K 6812 |
Box 4.4: 69.8K to 20.0M
| 69.8K 6982 |
71.5K 7152 |
73.2K 7322 |
75.0K 7502 |
76.8K 7682 |
78.7K 7872 |
80.6K 8062 |
82.5K 8252 |
84.5K 8452 |
86.6K 8662 |
88.7K 8872 |
90.9K 9092 |
93.1K 9312 |
95.3K 9532 |
97.6K 9762 |
100K 1003 |
| 102K 1023 |
105K 1053 |
107K 1073 |
110K 1103 |
113K 1133 |
115K 1153 |
118K 1183 |
121K 1213 |
124K 1243 |
127K 1273 |
130K 1303 |
133K 1333 |
137K 1373 |
140K 1403 |
143K 1433 |
147K 1473 |
| 150K 1503 |
154K 1543 |
158K 1583 |
162K 1623 |
165K 1653 |
169K 1693 |
174K 1743 |
178K 1783 |
182K 1823 |
187K 1873 |
191K 1913 |
196K 1963 |
200K 2003 |
205K 2053 |
210K 2103 |
215K 2153 |
| 221K 2213 |
226K 2263 |
232K 2323 |
237K 2373 |
243K 2433 |
249K 2493 |
255K 2553 |
261K 2613 |
267K 2673 |
274K 2743 |
280K 2803 |
287K 2873 |
294K 2943 |
301K 3013 |
309K 3093 |
316K 3163 |
| 324K 3243 |
332K 3323 |
340K 3403 |
348K 3483 |
357K 3573 |
365K 3653 |
374K 3743 |
383K 3833 |
392K 3923 |
402K 4023 |
412K 4123 |
422K 4223 |
432K 4323 |
442K 4423 |
453K 4533 |
464K 4643 |
| 475K 4753 |
487K 4873 |
499K 4993 |
511K 5113 |
523K 5233 |
536K 5363 |
549K 5493 |
562K 5623 |
576K 5763 |
590K 5903 |
604K 6043 |
619K 6193 |
634K 6343 |
649K 6493 |
665K 6653 |
681K 6813 |
| 698K 6983 |
715K 7153 |
732K 7323 |
750K 7503 |
768K 7683 |
787K 7873 |
806K 8063 |
825K 8253 |
845K 8453 |
866K 8663 |
887K 8873 |
909K 9093 |
931K 9313 |
953K 9533 |
976K 9763 |
1.00M 1004 |
| 1.50M 1504 |
2.00M 2004 |
2.49M 2494 |
3.01M 3014 |
4.02M 4024 |
4.99M 4994 |
5.90M 5904 |
6.81M 6814 |
7.50M 7504 |
8.25M 8254 |
9.09M 9094 |
10.0M 1005 |
15.0M 1505 |
20.0M 2005 |
Specifications
| Resistor Size | 0805 |
| Number of Values | 510 |
| Resistance Range | 0Ω to 20MΩ, 0Ω jumper < 0.05Ω |
| Tolerance | 1% |
| Power Rating | 1/8W |
| Max. Working Voltage | 150V |
| Max. Overload Voltage | 300V |
| Dielectric Withstanding Voltage | 300V |
| Operating Temperature | −55°C to 155°C |
| Temperature Coefficient | ±100 to ±200ppm/°C |
| Resistance Series | All E-96 values |
| Pieces per Value | 300 for commonly used values, 50 for rarely used values |
| Enclosure | 4 × 128-bin Super SMD Component Enclosure™ |
Applications
Typical uses include circuit development, prototyping, troubleshooting, board rework, and keeping an engineering or repair bench stocked with a full range of values.
| Weight | 8 lbs |
|---|---|
| Dimensions | 12 × 10 × 10 in |
| Package Size |
