R06E96 50 300PCD 0603 1% SMD Differential Resistor Kit 510 Values
$309.00
R06E96-50-300 is a 0603 1% SMD differential resistor kit with 510 values, featuring 50 pieces per rarely used value and 300 pieces per commonly used value in a sturdy snap-lockable enclosure.
Product Overview
The R06E96-50-300 is a 0603 1% SMD differential resistor kit covering all 510 values of the E-96 series. Each value is pre-sorted into its own lidded and labeled bin, so locating a specific resistor takes seconds instead of a parts-drawer search.
Quantities are matched to how often a value is actually used: 300 pieces of each commonly used value and 50 pieces of each rarely used value. The kit therefore lasts far longer in service without tying up stock in values that are rarely pulled. It ships in a set of 4 Super SMD Component Enclosures, each with 128 individually lidded and labeled bins.
Resistance vs. Marking Code
The bin lids are labeled with resistance values, but each 0603 resistor carries only a marking code. Most values use a 3-character EIA-96 code: two digits for the value and one letter for the multiplier. The three lowest values are marked 0 (0Ω), R10 (0.10Ω) and R50 (0.50Ω). The 510 values are split across 4 boxes, numbered 4.1 to 4.4, and each table below follows the bin layout of one box.
Box 4.1: 0.0Ω to 147Ω
| 0.0Ω 0 |
0.10Ω R10 |
0.50Ω R50 |
1.00Ω 01Y |
1.50Ω 18Y |
2.00Ω 30Y |
2.49Ω 39Y |
3.01Ω 47Y |
4.02Ω 59Y |
4.99Ω 68Y |
5.90Ω 75Y |
6.81Ω 81Y |
7.50Ω 85Y |
8.25Ω 89Y |
9.09Ω 93Y |
10.0Ω 01X |
| 10.2Ω 02X |
10.5Ω 03X |
10.7Ω 04X |
11.0Ω 05X |
11.3Ω 06X |
11.5Ω 07X |
11.8Ω 08X |
12.1Ω 09X |
12.4Ω 10X |
12.7Ω 11X |
13.0Ω 12X |
13.3Ω 13X |
13.7Ω 14X |
14.0Ω 15X |
14.3Ω 16X |
14.7Ω 17X |
| 15.0Ω 18X |
15.4Ω 19X |
15.8Ω 20X |
16.2Ω 21X |
16.5Ω 22X |
16.9Ω 23X |
17.4Ω 24X |
17.8Ω 25X |
18.2Ω 26X |
18.7Ω 27X |
19.1Ω 28X |
19.6Ω 29X |
20.0Ω 30X |
20.5Ω 31X |
21.0Ω 32X |
21.5Ω 33X |
| 22.1Ω 34X |
22.6Ω 35X |
23.2Ω 36X |
23.7Ω 37X |
24.3Ω 38X |
24.9Ω 39X |
25.5Ω 40X |
26.1Ω 41X |
26.7Ω 42X |
27.4Ω 43X |
28.0Ω 44X |
28.7Ω 45X |
29.4Ω 46X |
30.1Ω 47X |
30.9Ω 48X |
31.6Ω 49X |
| 32.4Ω 50X |
33.2Ω 51X |
34.0Ω 52X |
34.8Ω 53X |
35.7Ω 54X |
36.5Ω 55X |
37.4Ω 56X |
38.3Ω 57X |
39.2Ω 58X |
40.2Ω 59X |
41.2Ω 60X |
42.2Ω 61X |
43.2Ω 62X |
44.2Ω 63X |
45.3Ω 64X |
46.4Ω 65X |
| 47.5Ω 66X |
48.7Ω 67X |
49.9Ω 68X |
51.1Ω 69X |
52.3Ω 70X |
53.6Ω 71X |
54.9Ω 72X |
56.2Ω 73X |
57.6Ω 74X |
59.0Ω 75X |
60.4Ω 76X |
61.9Ω 77X |
63.4Ω 78X |
64.9Ω 79X |
66.5Ω 80X |
68.1Ω 81X |
| 69.8Ω 82X |
71.5Ω 83X |
73.2Ω 84X |
75.0Ω 85X |
76.8Ω 86X |
78.7Ω 87X |
80.6Ω 88X |
82.5Ω 89X |
84.5Ω 90X |
86.6Ω 91X |
88.7Ω 92X |
90.9Ω 93X |
93.1Ω 94X |
95.3Ω 95X |
97.6Ω 96X |
100Ω 01A |
| 102Ω 02A |
105Ω 03A |
107Ω 04A |
110Ω 05A |
113Ω 06A |
115Ω 07A |
118Ω 08A |
121Ω 09A |
124Ω 10A |
127Ω 11A |
130Ω 12A |
133Ω 13A |
137Ω 14A |
140Ω 15A |
143Ω 16A |
147Ω 17A |
Box 4.2: 150Ω to 3.16K
| 150Ω 18A |
154Ω 19A |
158Ω 20A |
162Ω 21A |
165Ω 22A |
169Ω 23A |
174Ω 24A |
178Ω 25A |
182Ω 26A |
187Ω 27A |
191Ω 28A |
196Ω 29A |
200Ω 30A |
205Ω 31A |
210Ω 32A |
215Ω 33A |
| 221Ω 34A |
226Ω 35A |
232Ω 36A |
237Ω 37A |
243Ω 38A |
249Ω 39A |
255Ω 40A |
261Ω 41A |
267Ω 42A |
274Ω 43A |
280Ω 44A |
287Ω 45A |
294Ω 46A |
301Ω 47A |
309Ω 48A |
316Ω 49A |
| 324Ω 50A |
332Ω 51A |
340Ω 52A |
348Ω 53A |
357Ω 54A |
365Ω 55A |
374Ω 56A |
383Ω 57A |
392Ω 58A |
402Ω 59A |
412Ω 60A |
422Ω 61A |
432Ω 62A |
442Ω 63A |
453Ω 64A |
464Ω 65A |
| 475Ω 66A |
487Ω 67A |
499Ω 68A |
511Ω 69A |
523Ω 70A |
536Ω 71A |
549Ω 72A |
562Ω 73A |
576Ω 74A |
590Ω 75A |
604Ω 76A |
619Ω 77A |
634Ω 78A |
649Ω 79A |
665Ω 80A |
681Ω 81A |
| 698Ω 82A |
715Ω 83A |
732Ω 84A |
750Ω 85A |
768Ω 86A |
787Ω 87A |
806Ω 88A |
825Ω 89A |
845Ω 90A |
866Ω 91A |
887Ω 92A |
909Ω 93A |
931Ω 94A |
953Ω 95A |
976Ω 96A |
1.00K 01B |
| 1.02K 02B |
1.05K 03B |
1.07K 04B |
1.10K 05B |
1.13K 06B |
1.15K 07B |
1.18K 08B |
1.21K 09B |
1.24K 10B |
1.27K 11B |
1.30K 12B |
1.33K 13B |
1.37K 14B |
1.40K 15B |
1.43K 16B |
1.47K 17B |
| 1.50K 18B |
1.54K 19B |
1.58K 20B |
1.62K 21B |
1.65K 22B |
1.69K 23B |
1.74K 24B |
1.78K 25B |
1.82K 26B |
1.87K 27B |
1.91K 28B |
1.96K 29B |
2.00K 30B |
2.05K 31B |
2.10K 32B |
2.15K 33B |
| 2.21K 34B |
2.26K 35B |
2.32K 36B |
2.37K 37B |
2.43K 38B |
2.49K 39B |
2.55K 40B |
2.61K 41B |
2.67K 42B |
2.74K 43B |
2.80K 44B |
2.87K 45B |
2.94K 46B |
3.01K 47B |
3.09K 48B |
3.16K 49B |
Box 4.3: 3.24K to 68.1K
| 3.24K 50B |
3.32K 51B |
3.40K 52B |
3.48K 53B |
3.57K 54B |
3.65K 55B |
3.74K 56B |
3.83K 57B |
3.92K 58B |
4.02K 59B |
4.12K 60B |
4.22K 61B |
4.32K 62B |
4.42K 63B |
4.53K 64B |
4.64K 65B |
| 4.75K 66B |
4.87K 67B |
4.99K 68B |
5.11K 69B |
5.23K 70B |
5.36K 71B |
5.49K 72B |
5.62K 73B |
5.76K 74B |
5.90K 75B |
6.04K 76B |
6.19K 77B |
6.34K 78B |
6.49K 79B |
6.65K 80B |
6.81K 81B |
| 6.98K 82B |
7.15K 83B |
7.32K 84B |
7.50K 85B |
7.68K 86B |
7.87K 87B |
8.06K 88B |
8.25K 89B |
8.45K 90B |
8.66K 91B |
8.87K 92B |
9.09K 93B |
9.31K 94B |
9.53K 95B |
9.76K 96B |
10.0K 01C |
| 10.2K 02C |
10.5K 03C |
10.7K 04C |
11.0K 05C |
11.3K 06C |
11.5K 07C |
11.8K 08C |
12.1K 09C |
12.4K 10C |
12.7K 11C |
13.0K 12C |
13.3K 13C |
13.7K 14C |
14.0K 15C |
14.3K 16C |
14.7K 17C |
| 15.0K 18C |
15.4K 19C |
15.8K 20C |
16.2K 21C |
16.5K 22C |
16.9K 23C |
17.4K 24C |
17.8K 25C |
18.2K 26C |
18.7K 27C |
19.1K 28C |
19.6K 29C |
20.0K 30C |
20.5K 31C |
21.0K 32C |
21.5K 33C |
| 22.1K 34C |
22.6K 35C |
23.2K 36C |
23.7K 37C |
24.3K 38C |
24.9K 39C |
25.5K 40C |
26.1K 41C |
26.7K 42C |
27.4K 43C |
28.0K 44C |
28.7K 45C |
29.4K 46C |
30.1K 47C |
30.9K 48C |
31.6K 49C |
| 32.4K 50C |
33.2K 51C |
34.0K 52C |
34.8K 53C |
35.7K 54C |
36.5K 55C |
37.4K 56C |
38.3K 57C |
39.2K 58C |
40.2K 59C |
41.2K 60C |
42.2K 61C |
43.2K 62C |
44.2K 63C |
45.3K 64C |
46.4K 65C |
| 47.5K 66C |
48.7K 67C |
49.9K 68C |
51.1K 69C |
52.3K 70C |
53.6K 71C |
54.9K 72C |
56.2K 73C |
57.6K 74C |
59.0K 75C |
60.4K 76C |
61.9K 77C |
63.4K 78C |
64.9K 79C |
66.5K 80C |
68.1K 81C |
Box 4.4: 69.8K to 20.0M
| 69.8K 82C |
71.5K 83C |
73.2K 84C |
75.0K 85C |
76.8K 86C |
78.7K 87C |
80.6K 88C |
82.5K 89C |
84.5K 90C |
86.6K 91C |
88.7K 92C |
90.9K 93C |
93.1K 94C |
95.3K 95C |
97.6K 96C |
100K 01D |
| 102K 02D |
105K 03D |
107K 04D |
110K 05D |
113K 06D |
115K 07D |
118K 08D |
121K 09D |
124K 10D |
127K 11D |
130K 12D |
133K 13D |
137K 14D |
140K 15D |
143K 16D |
147K 17D |
| 150K 18D |
154K 19D |
158K 20D |
162K 21D |
165K 22D |
169K 23D |
174K 24D |
178K 25D |
182K 26D |
187K 27D |
191K 28D |
196K 29D |
200K 30D |
205K 31D |
210K 32D |
215K 33D |
| 221K 34D |
226K 35D |
232K 36D |
237K 37D |
243K 38D |
249K 39D |
255K 40D |
261K 41D |
267K 42D |
274K 43D |
280K 44D |
287K 45D |
294K 46D |
301K 47D |
309K 48D |
316K 49D |
| 324K 50D |
332K 51D |
340K 52D |
348K 53D |
357K 54D |
365K 55D |
374K 56D |
383K 57D |
392K 58D |
402K 59D |
412K 60D |
422K 61D |
432K 62D |
442K 63D |
453K 64D |
464K 65D |
| 475K 66D |
487K 67D |
499K 68D |
511K 69D |
523K 70D |
536K 71D |
549K 72D |
562K 73D |
576K 74D |
590K 75D |
604K 76D |
619K 77D |
634K 78D |
649K 79D |
665K 80D |
681K 81D |
| 698K 82D |
715K 83D |
732K 84D |
750K 85D |
768K 86D |
787K 87D |
806K 88D |
825K 89D |
845K 90D |
866K 91D |
887K 92D |
909K 93D |
931K 94D |
953K 95D |
976K 96D |
1.00M 01E |
| 1.50M 18E |
2.00M 30E |
2.49M 39E |
3.01M 47E |
4.02M 59E |
4.99M 68E |
5.90M 75E |
6.81M 81E |
7.50M 85E |
8.25M 89E |
9.09M 93E |
10.0M 01F |
15.0M 18F |
20.0M 30F |
Specifications
| Resistor Size | 0603 |
| Number of Values | 510 |
| Resistance Range | 0Ω to 20MΩ, 0Ω jumper < 0.05Ω |
| Tolerance | 1% |
| Power Rating | 1/10W |
| Max. Working Voltage | 75V |
| Max. Overload Voltage | 150V |
| Dielectric Withstanding Voltage | 100V |
| Operating Temperature | −55°C to 155°C |
| Temperature Coefficient | ±100 to ±200ppm/°C |
| Resistance Series | All E-96 values |
| Pieces per Value | 300 for commonly used values, 50 for rarely used values |
| Enclosure | 4 × 128-bin Super SMD Component Enclosure™ |
Applications
Typical uses include circuit development, prototyping, troubleshooting, board rework, and keeping an engineering or repair bench stocked with a full range of values.
| Weight | 8 lbs |
|---|---|
| Dimensions | 12 × 10 × 10 in |
| Package Size |
