ATLS25A219GUI PWM Laser Driver, 25A, High Voltage DC Input

ATLS25A219GUI PWM Laser Driver, 25A, High Voltage DC Input

$333.80

Constant Current Laser Diode Driver
Input Voltage (VVPS): 12V ~ 40V
Output Voltage: 0.85V ~ 32V (0.1VVPS ~ 0.8VVPS)
Max. Output Current: 25A
Noise: <20µAP-P

Out of stock

SKU: ATLS25A219GUI Category:

Product Overview

The ATLS25A219GUI is a constant current laser diode driver designed for driving up to 25A laser diodes. It operates from a 12V ~ 40V power supply and delivers stable current output across a 0.85V ~ 32V load voltage range.
The driver is suitable for applications including DPSSL, EDFA, Fiber Lasers, High Current Laser Diode Arrays.

Specifications

Input Voltage (VVPS) 12V ~ 40V
Output Voltage 0.85V ~ 32V (0.1VVPS ~ 0.8VVPS)
Max. Output Current 25A
Noise <20µAP-P
Stability <±20mA @25A, -20°C ~ 80°C
Modulation BW DC ~ 10kHz
Efficiency 95% (IOUT=25A, VLDA=30V, VVPS=40V), built-in heat sink
Drive Type Switch
Package Type Chassis
Input Type DC High
Operating Temperature (°C) -40 ~ 110
Dimension (mm) 63.0×61.0×16.7
Weight 2 lbs
