ATE1-TCHE-127-4B 38W 4A Thermal Cycling High-Efficiency Thermoelectric Cooler (TEC) Module (39.7×39.7mm)
$27.00
Thermal Cycling High-Efficiency Thermoelectric Cooler (TEC / Peltier Module)
Qmax: 38 W
Imax: 4 A
Vmax: 18.1 V
ΔTmax: 83°C
Dimensions: 39.7 × 39.7 × 4.5 mm
Sealing: Non-sealed
Available on backorder
Product Overview
ATE1-TCHE-127-4B is a non-sealed, single-stage thermoelectric cooler (TEC / Peltier module) rated 4 A, 38 W Qmax and 83°C ΔTmax in a 39.7 × 39.7 mm, 127-couple package (18.1 V Vmax).
Standard non-sealed construction for dry, temperature-controlled environments. Ideal for temperature control of PCR thermal cyclers and high-duty-cycle bio-instruments; pairs with ATI TEC controllers and NTC thermistors.
Specifications
| Qmax | 38 W |
| Imax | 4 A |
| Vmax | 18.1 V |
| ΔTmax | 83°C |
| Lc | 39.7 mm |
| W | 39.7 mm |
| H | 4.5 mm |
| Construction / Temp. Range | Non-sealed, single-stage; -55°C to +85°C |
