Wide Range High Voltage Isolated DC-DC Power Modules AIDCW600V12V2A1

Availability: In Stock

FEATURES

●Wide Input Power Voltage Range: 210 to 1200VDC ●Output Voltage: 12V ±0.24V ●Max. Output Current: 2A ●High Efficiency: 79% ●Output Ripple Voltage: ±1% @20MHz ●Isolation Voltage: 1500VDC ●Output Short-Circuit Protection: Automatic Recovery ●Full Aluminum Housing for Complete Shielding  ●Operating Temperature Range: −40°C ~ +85°C ●100 % Lead (Pb)-free and RoHS Compliant

APPLICATIONS

⚫Sustaining Ion Pumps,⚫ Spectral Analysis⚫ Electrophoresis⚫ Particle Accelerator⚫ Capillary Electrophoresis⚫ Piezo Devices⚫ Photo Multiplier Tubes⚫ Avalanche Photo Diodes
Part Number STOCK 1-9PCs 10-49PCs 50-99 PCs 100-99999 PCs Buy Now Datasheet Add TO WATCHLIST
AIDCW600V12V2A1 0 $65 $60 $55 $50

This power module, AIDCW600V12V2A1, is designed  for achieving DC-DC conversion from high voltage to  low voltage as a power supply source. It is widely  used in scientific research and other fields.
