FEATURES
●Voltage Measurement: Maximum voltage measurement of 600V with surge protection up to 6kV.
●Current Measurement: Equipped with an 11A, 1000V 17 kA FAST Fuse for current measurement
●Display: Digital display with 6,000 counts and 4 updates per second, plus a 33-segment bar graph with 32 updates per second.
●Temperature: Operating temperature range of −10°C to +50°C, with a storage range of −40°C to +60°C.
●Altitude: Rated for operation up to 2,000 meters above sea level.
●Battery Life: Operates on a 9-volt alkaline battery, with a typical life of 400 hours without using the backlight.
●Safety Standards: Complies with ANSI/ISA, CAN/CSA, UL, IEC/EN safety standards for CAT III 600V, Pollution Degree 2, and EMC.
●Certifications: UL, CSA, TÜV, VDE certified.
●IP Rating: IP42 dust and water protection.
